WMF72 Advanced Wireless Multi-Format Presentation Switch

• 4K multi-format multi-view presentation switch
• Features HDMI, USB-C, AirPlay, Miracast®, Chromecast® and Blustream wireless dongle support which can be switched to dual HDMI outputs
• Dual HDMI output supports mirror or desktop extension for managed soure control within advanced video conferencing set-ups
• Multiview presentation with up to 5 concurrent video signals and configurable screen layout
• In-built video scaler with output timing up to 4K 60Hz 4:4:4
• USB-C connection for BYOM, with DP, USB, 1Gbps network and up to 65W power charging
• HDMI & USB Type B connection for BYOM, with USB and 1Gbps network via USB Type B connection
• Localised 2.4G/5G WiFi hotspot to host AirPlay, Miracast® and Chromecast® local point-to-point mode (up to 1080p 30Hz)
• Dual LAN connection for integration to existing network infratructures
• Supports USB camera and MIC over WiFi up (1080p 30Hz)
• Supports USB touch-back feature via WMF-USBC-D and WMF-HDMI-D dongles and Miracast®*
• Audio breakout to balanced / unbalanced analogue L/R audio
• Web interface module for control and configuration of switch
• OSD control with preview function
• Whiteboard and screen overlay annotation feature
• Control via front panel, RS-232 and TCP/IP with manual or auto source selection
