Blustream  |  SKU: ACM500 | Item No. 0104-0180

ACM500 Advanced Control Module for IP500UHD-TZ

Login for pricing

MSRP: $861.00

Product Features

  • Web interface module for configuration and control of Blustream IP500UHD and IP510UHD SDVoE 10GbE Multicast systems
  • Intuitive 'drag & drop' source selection with video preview feature for active monitoring of system status
  • Advance signal management for independent routing of IR, RS-232, USB/KVM, audio and video
  • Auto system configuration
  • 2x RJ45 LAN connections to bridge existing network to Multicast video distribution network, resulting in:     - Better system performance as network traffic is separated     - No advanced network setup required     - Independent IP address per LAN connection  - Allows simplified TCP/IP control of Multicast system
  • Dual RS-232 ports for control of the Multicast system, or pass-through of control to remote third party devices
  • 5V/12V IR integration for control of Multicast system
  • PoE (Power over Ethernet) to power Blustream product from PoE switch
  • Local 12V power supply (optional) should Ethernet switch not support PoE
  • Support for iOS and Android App control
  • 3rd Party drivers available for all major control brands

Specifications

  • Dimensions (W x D x H): 190.4mm x 93mm x 25mm
  • Shipping Weight (Kit): 0.6kg

Related Files

Payment & Security
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
The ACM500 Control Module features advanced third party control of the SDVoE 10GbE Multicast system using TCP/IP, RS-232 and IR. The ACM500 includes a web interface module for control and configuration of the Multicast system and features 'drag and drop' source selection with video preview and independent routing of IR, RS-232, USB / KVM, Audio and Video.
