C44CS-KIT 4x4 HDBaseT™ Matrix Kit - 4K 60Hz 4:4:4 (Receivers included)

• Advanced HDBaseT™ technology offering distribution of video and audio over a single CAT cable
• Advanced Colour Space Conversion (CSC) supports HDMI 2.0 18Gbps specification including HDR*
• Features 4 x HDMI inputs which can be independently routed to 4 x HDBaseT™ outputs
• Output 1 features simultaneous HDMI and HDBaseT™ output
• Video down-conversion on HDBaseT™ outputs allowing a display only capable of supporting lower video resolutions (4K 60Hz 4:2:0 or 1080p) to receive 4K 60Hz 4:4:4 video content while still showing maximum original 4K UHD resolution on remaining video outputs
• Supports 4K 60Hz 4:4:4 UHD video up to 40m
• Extends HDMI 1080p video up to 70m
• Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K
• Supports all known HDMI audio formats including Dolby TrueHD, Dolby Atmos, Dolby Digital Plus and DTS-HD Master Audio transmission
• Web interface module for control and configuration of matrix
• Supports bi-directional IR on all HDBaseT™ outputs
• Control via front panel, iOS / Android App, IR, RS-232 or TCP/IP
• Supports 12V PoC (Power over Cable) to power compatible HDBaseT™ receivers
• Supplied with Blustream IR receivers and emitters
• 3rd party drivers available for all major control brands
• 1U design for 19” rack mount integration - mounting kit included
• Advanced EDID management and HDCP 2.2 compliant

1 x C44CS Matrix
4 x RX70CSL Receivers
1 x Rack Mounting Kit
4 x Mounting Kits for RX70CSL
4 x Mounting Feet
1 x Remote Control
4 x IR Emitters
5 x IR Receivers
1 x Serial Cable - DB9 to DB9
1 x IR Control Cable - 3.5mm-3.5mm Cable
1 x Quick Reference Guide
IEC Power Cable(s)

Spec Sheet
