RTI  |  SKU: XP-6s | Item No. 0104-0136

XP6s XP Based Central Processor

Login for pricing

MSRP: $976.95

Description

The second generation of the incredibly popular XP-6, the redesigned XP-6s control processor is the perfect centerpiece of any professionally installed control system. With a rack-mountable design, faster internal CPU and bolstered with 512 MB of RAM memory, the powerhouse processor automates and enhances the operation of A/V, security, lighting, HVAC, and more.



Product Features
  • 2-Way - Convenient and reliable control with status feedback from controlled devices such as on/off or arm/disarm status, dimming value of lights, playlists, available stations.
  • RS-232 - Three (3) control ports for 3-wire connection with the capability of polling status feedback from controlled devices or systems.
  • Relay - Three (3) built-in low voltage dry contacts that provide contact closure or switching control for loads up to 3A/30VDC (external power supply required).
  • MPIO / Infrared - Six (6) Multi-Purpose Input/Output control ports that allows for infrared control with infrared emitters, blasters and repeaters and connecting voltage sensors or RS-232 communication modules.
  • Sense Input / Voltage Trigger - Three (3) programmable 100mA/2VDC outputs to control and high voltage external relay in amplifiers or other devices to turn them on or off when a sense input detects contact closure from switches, windows or doors. Sense inputs can also be used to trigger a programmed control command or macro.
  • Expansion Port - Proprietary communication port that allows bidirectional control communication with RTI touchpanels and keypads.
  • Ethernet - Standard 10/100 BaseT network connection for bidirectional control communication with RTI remotes, touch panels and devices that are controlled over IP network.
  • Zigbee - Standard wireless Zigbee connection for bidirectional control communication with RTI remotes via ZM-24 Zigbee transceiver module.
  • RF 433 MHz - Wireless RF communication on the 433 MHz band for unidirectional control communication with RTI remotes.
  • Astronomical Clock - Built-in clock that syncs through an internet connection allows to schedule time-based events to automate all aspects of the installed environment, including climate, lighting, music, and much more.
  • Rack-Mount - Allows for mounting the unit into a standard 19” wide rack or placing on any surface using the included feet.

In the Box
Payment & Security
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
  • Length
    8.5in
  • Height
    1.72 in
  • Width
    6 in
  • Weight
    2 lb
