PLIXUS AE-R Plixus Audio Engine 19" Rack-mountable Recording Device

» Easy built-in recording
» No PC required for core functionality
» Seamless combination of wired and wireless units
» Wireless range extension
» (Confero only) 802.1X (MD5, TLS, PEAP-MSCHAPv2) for
LAN port only
» Combinations for wireless room split/combine
application
» USB port for expandable memory to record longer
meetings (volumes up to 500 GB)
» I ntegrated dynamics processor with programmable
threshold, ratio, attack and release of noise gate, AGC
and limiter functions.
» Supports interpretation with a default of 11 languages
+ floor (can be extended to 63 + floor through different
licenses)

Buttons & Modes
» ON/OFF Power button
» A volume dial on the front allows direct adjustment of
the system volume
» Single push button to start or stop recordings
» LED indicator to show recording status (ON/OFF)
» DLP switch to enable and disable power to the Plixus
conference ports

» 2 Power connectors
» 4 Conference network ports
» DLP switch
» 2 Dante ports (not usable)
» 1 USB 2.0 ports
» LAN port
» 1 Balanced XLR audio input
» 1 Balanced XLR audio output
» 2 Unbalanced Cinch audio inputs
» 2 Unbalanced Cinch audio outputs
